HD-C NEON hose with new, REFLECTING marking
ZV 19.1 TD
ZV 19 manually operated dispensing nozzle, DN 19 (3/4"), up to 100 ltr./min. Special version for chemicals/solvents with PTFE seals.
RS 11/2 x 2 SS
Reducer Female/Male
GasGuard LPG nozzle GG20
With long connector nut to access 'hard to reach' fill points. Economic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.
Oasis Fill Valves at CNG service station
ELAFLEX Hamburg
Assembling dispensing hose
Aircraft refuelling hoses
TW-E, HD-C Neon, PHD-F, HD-C
Nozzle boot NB-ZVF 50
for ZVF 50 Oberflügel-Zapfventile
MK "TW" female couplers of stainless steel
special types with bent lever
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Manufacturing of turned parts
Hose Safety Break for LPG
ARK 19
Refuelling with ZVA Slimline 2 nozzle
Scuffguard, Product Sleeve and Colour Sleeve in grey special colour
UTS hose assembly
Colour production plant
IBC Hose Coupling MC 38-S 60 SS, MX 38-S 60 SS
direct connection to the standard outlet S 60 of IBC
Slimline 21 green
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
Flexible bronze pipe connectors
Installed in suction pipe between dispenser and underground storage tank
Coax hose assembly, section view
Stainless steel couplings with PFA coating, type "...SSE"
Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
ElaSil® Silicone hose assemblies DN 13-102
For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection
ZVA Slimline 2 GRVP - spout with vapour suction inlet
ELAPHARM and SD Pyropal steam hose
Pharmaceutical production
CBC-C
Cryogenic Breakaway Coupling for LNG with cable release: before release
Camlock Cam Locking hose tails AMK-St 50 Ms and AVK-St 50 Ms (brass)
ELAFLEX Hamburg
Assembling bunker hose
UTS hose assembly, rail tanker top loading
ELAFLEX Hamburg
Aerial view (left to right): Technical dept., small aisle stock, stock with loading ramps
Flexible bronze pipe connector BWO
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
CHD 32
Lilac Band chemical hose without helix, DN 32
LNG Refuelling
LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable
