Media Library / Images

ZVA Slimline 2 GR, black, guard 3 - side view

Terminal / gantry: 'Polypal Oil 100' and 'TW 100' hose assemblies for bottom loading of road tankers

Hoses for Liquefied Petroleum Gas / Autogas

LPG 13, LPG 16 black/orange, LPG 19

ERV-G 80.TW

"Yellow Band" Rubber Expansion Joints; tank truck

Oasis BV706 ball valves with Code 62 flange and SAE connection, for CNG

Oil production Kuwait

TW and STW hose assemblies with SFC hose flanges

GasGuard LPG nozzles

and LPG 16 orange hose assemblies for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane.

ZVF 50 UL 91 / green

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

ELAFLEX Hamburg

Stock special flanges

LNG Refuelling

LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, bonding cable

Urea solution for trucks: ZVA HV for AdBlue® nozzle

System comparison Camlock Cam Locking Couplings

Industry standard vs. ELAFLEX EASYLOC

Group picture

TW 100, DDC-M100 4", Hose Reel VR Spring Rewind System, ZVA Slimline 2 GR, ERV-G 1000, ERV-BR 300

Ultra Fast Fill Quick Coupler 350 bar

for Hydrogen

Slimline 16 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

Safety Swivel Break

SSB 32

GasGuard LPG nozzles: optional Magnet in the guard

For contactless activation of dispensers with reed switch technology

ZVF 50 JET for aircraft refuelling

ZVA Slimline 2 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

ERV-G 50x160

Fuel mixer / blender

TWD-W coupling seal

NBR white

GasGuard LPG nozzle GG1DN

suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure: 1.7 cm³.

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (German)

Connection aircraft refueller to flanged hose assembly

ERV-G 100 TW, HD 100 C, TW-flange

Graphic Drip Stop spout for ZVA Slimline 2 nozzles

Production MannTek, Sweden

PHD 100, airport depot

M 16-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, black.

Road tanker for heating oil delivery, HD hose assembly, ZH 50 nozzle, MK 80 Ms coupler with VB 80 Al dust plug
