SG 80-TW1 Al

Sight glass with rods, with TW flanges to DIN 28460

Graphic, components of a ZVA Slimline 2 GR nozzle for vapour recovery

DDC-V 25 Al; DDC-K 25

Dry Disconnect Coupling as probe/sampling unit connection at aircraft refueller

Elaflon Plus FEP hose assemblies, SBC Safety Breakaway Couplings

Ship loading various media - STW 150 and UTS 150 hose assemblies

ZAF Coax adapter (splitter valve) at petrol station dispenser

ELAFLEX Hamburg

Certificate pressure test

Unloading petroleum products at the service station (road tanker to UST)

LG hose assembly for gravity discharge

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C

Slimline 16 yellow

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

LeverAssist reduces the hold-open force by 90%, for comfortable refuelling in countries where latching is not allowed

Type PCS 38 (Polypal Clean DN 38 mm)

Elaflex hose assemblies

Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings

PAL hoses for the chemical industry

ARK 19 Safety Break (Hose Break) at LPG Autogas dispenser

Reassembly on site without tools

MC 75-3" Ms

Female hose coupling for hoses, brass, with Spannloc clamps

M 16-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, green.

Motorcycle refuelling at the petrol station

ZVA Slimline 2 GR with special short spout

Fluorflex FXD universal hose assemblies with anti kinking spiral KSS

extremely flexible PTFE hose with maximum bending radius and safety against kinking

Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle

Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt

Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry

RS 2 x 78 SS

Reducer Female/Male

KR 50 - 21/2", HD reel hose

Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

DDC-M 25-1" SS

MannTek Dry Disconnect Coupling, DN 25, stainless steel

BD 63 Hose Beads

to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.

Safety Swivel Break

SSB 16 SS

Oasis CNG refuelling equipment:

Ultra Fast Fill System (Diagram, English)

Tecnopal 38

Chemical hose to EN 12115 for alkalis, acids, solutions, alcohols, polar solvents, acetates, aldehydes, esters, ketones, hot water, hot air (not oily).
