ELAFLEX Tanktechnik, Production Plettenberg / Germany
Contour check
Slimline dispensing hose SF (sulfur-free)
Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose
DEC – Dry Evotek Couplings:
dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling
LPG Autogas Adapter (filler inlet) BAYO
Bayonet connection
Nozzles with SIGHT GLASS
ZVA Slimline 2 with SG 1" Al, ZVA Slimline 2 GR with SG-COAX
ERV-G
with vacuum support spiral
ZVA Slimline 2 nozzles special version, Slimline dispensing hoses blue / red
Thailand
ELAFLEX Hamburg
Hose assemblies pressure testing (hydrostatic test)
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, bonding cable
Cabinet of road tanker:
MK 80-32 TW coupler with bent lever, VB 80 P dust plug
Road tanker with hose reel spring rewind blue, ZVA Slimline 2 green
Mobile refuelling
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
KWZ x MK 80-32°
Rail car adapter with TW coupler, bent lever
MannTek, DDC-M 50, DEC-M 38, DDC-M 80, DCC-M 50, DGC-M 80, DAC-M 65, DAC-V 65
Functioning principle of MannTek DDC Dry Disconnect Couplings
closed - open
DDC-M 100-4" with TW 100 hose assembly
Dry Disconnect Coupling and road tanker hose
AVKI 38 SSE
Camlock male adapter. Material: stainless steel with universally resistant PFA coating (red)
UTL 50 universal hose with MannTek Dry Disconnect Coupling DDC-M 65 - 21/2" Ms
ZVA Slimline 2 GR, ZVA Slimline 2
Petrol station Germany
Boat refuelling
ZVA Slimline 25, HD hose assembly
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
LeverAssist reduces the hold-open force by 90%, for comfortable refuelling in countries where latching is not allowed
DDC-M 80-3" SS
MannTek Dry Disconnect Coupling, DN 80, stainless steel
Customer protected special design ZVA Slimline 2 & ZVA Slimline 2 GR nozzles
Dantec Production hose
Composite hoses: hose with customer braning, application of outer helix
Ship bunkering
FHD hose assembly, flange connection
EL 800 Earthing Strap with vulcanized copper strand
Electrically conductive bonding. Use for road tankers for petroleum based products, solvents, bulk tankers, forklifts, cable cars and cable Electro-Buses.
Elaflon PTFE 38 hose assembly with RMC 38 SS foodstuff fitting
BD 63, HD 63 C
Aircraft refuelling hoses with ELAFLEX Hose Beads 'BD'. Details see Information 7.17
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 DISH nozzle
Rubber Expansion Joint ERV-CR 80.16
CR Expansion Joints for cold and warm water, swimming pool water, sea water, waste water (weakly sour or alkaline) also oil containing, cooling water with protective oils against corrosion, lubricating oil, grease and air, compressed air. Temperature range (depending on medium) - 25° C up to + 90° C, temporarily up to + 100° C. Electrically non-conductive.
