Road tanker hose assembly

with VKC 75 SS (TW male coupling stainless steel, one part, with Spannloc clamps, K-Ring), dust cap VB 80 SS & chain

PHD-F aircraft refuelling hose

PHD 63 F

LNG Refuelling

LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly with cover hose, bonding cable

ERV-GS

"Yellow Steel" Rubber Expansion Joints / ship engine room; Netherlands

DDC-M 65-2 1/2" Al

MannTek Dry Disconnect Coupling, aluminium

Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium

HD 50 C, VC 50 SS, SC 50 Al

ZVG 2 DISH nozzle for L.P. Gas / Autogas, LPG 16 hose assembly, ARK 19 Safety Break

MB 80 SSE

TW dust cap of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Manufacturing nozzle seat

MannTek DGC DryGasCoupling for L.P. Gas

DGC-V 80 F, DDC-K 3" NBR

Dispenser at the airport

ZVA 25 Avgas for overwing refuelling

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Automatic rod turning machines

Hot bitumen hose - loading (bunkering) ship

HB 100 hose assembly

MC 75-3" Ms

Female hose coupling for hoses, brass, with Spannloc clamps

ContiTech Production hose

braid

LNG Refuelling

N-LNG Nozzle, Soft-Stop-Position

Unloading petroleum products at the service station (road tanker to UST)

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose

ERV-W 80.16

WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

Elaflex Pacific (Australia)

Manufacturing GasGuard GG1 nozzle

FFBV 100, FFBV 80

MannTek Full Flow Ballvalves (FFBV), one way

Aircraft Refuelling Skid

HD-C hose assembly, ZVA 32 nozzle, SG1Al sight glass, hose reel made by ELAFLEX Italy

Terminal Railtanker

LTW 100, MK 100, VK 100, SBC 100-4, FFBV 100

ZVA 25 with Z-Swivel

Boat Refuelling

Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY

EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp

UTS hose assembly, rail tanker top loading

L.P.Gas home delivery:

LPG 38 hose assembly - Aboveground storage Tank

Camlock cam locking couplings:

Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)

ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies

Petrol station, Indonesia

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.
