Ship bunkering loading and unloading, Hose Reels, HD hose, ZV 500
Bunkerboat
Ship bunkering with LNG
towards the end of the bunkering process
Universal hose assembly UTL 63 with VC 63-3" SS / SS and MK-A 80 SS
Urea solution filling, truck:
'ZVA HV for AdBlue®' nozzle, 'Slimline 16 for AdBlue®' hose
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly with cover hose, bonding cable
Oasis PM104 Priority Panel / Manifold, for CNG
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
Vergleich visibility aircraft refuelling hoses - below: "Yellow Band" standard, top: "NEON" new version with reflecting bands
DCC Dry Cryogenic Coupling for LNG
Coupling process
ELAFLEX Hamburg
Assembling Spannfix hose clamps
Product Badges EK 145 with design to customer specification
ZVA_AdBlue_LV_2-Stufen-Anschlag_Step1
Use - 1/2
DAC-V 65, DAC-M 65
Coupling test facility
Storz Safety Couplings Type SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
SG1" 1x0 Al, EA075.1, EA375.0AF, DG 50.1 Al, DG 50.2 Al
L.P.Gas road tanker, Hose Reel with LPG 50, MannTek DGC
DGC-M 50 SS, DGC-K
ELAFLEX Hamburg
Hose assemblies, endoscope inspection hose
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®
old design
DDC-M 65-2 1/2" Al
MannTek Dry Disconnect Coupling, aluminium
DCC Dry Cryogenic Coupling for LNG
with cap
Drum filling
with CHS chemical hose assembly
Fixed Flange and hose tail of stailess steel
SFC 63.16 SS
ERV-G 80.TW
"Yellow Band" Rubber Expansion Joints; tank truck
ERV-G ... TW
Aircraft refueller
GasGuard LPG nozzle GG30
4-slot design to facilitate connection of the nozzle to the vehicle fill point. New nose piece design to reduce the released gas upon valve closure, incorporating improved gas release method to minimise the risk of splash back.
VSR vacuum support ring for ERV Rubber Expansion Joints
to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571
Equipment truck for dangerous goods accidents
suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
