ERV flange assembly medium sizes

Double Closing COAX Safety Break

CSB 21 DC

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Hose Reel spring rewind red, SL 19 black, ZVA Slimline 2 green

ELAFLEX refuelling equipment:

Quality is in the detail.

VB 80 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Slimline 21 green

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

M 16-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, black.

Fuel Grade Identification to EN 16942 standard, direct print on product badges for ZVA Nozzles

Picture 2

Road tanker with hose reel spring rewind blue, ZVA Slimline 2 green

Mobile refuelling

V-St 50 SSE

Male threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)

ZVG 2 ACME nozzle for L.P. Gas / Autogas

visible: Magnet within the guard for the dispenser Reed Switch

ZVA Slimline 2 DSA

DSA: Pressure Controlled Safety Shut-Off

Urea solution filling of a car: ZVA LV for AdBlue®

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

Grafik ARK 19

Safety Break for LPG (Autogas) dispensers. Hose Break. Reassembly after separation without tools.

IBC unloading

Female hose coupling MC 38-S60 SS (with Spannfix clamps) and LMS solvent hose. Direct connection of a hose assembly to the IBC.

PHD 63

Aircraft refuelling hose special type with non metallic plastic helix and thick wall for enhanced lateral stability. Burst pressure > 80 bar

SVX 50-2"

Male hose coupling of steel with Spannfix clamps

Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings

EA 866 scuffguard black with ZVG 2 DISH nozzle

The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space

M 16-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, blue.

BD 63 Hose Beads

to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.

M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, red.

Slimline quality dispensing hose for the forecourt

SL 21 black

Cabinet of road tanker:

hose tubes, TW hoses, TW couplings

Hose assembly TW 63 with SFX 63

TW hose with helix, 'TW' flange with hose tail and Spannfix clamps of aluminium

KWZ 3" Al

Rail tanker adapter with male thread connection, aluminium

ERV VSR:

ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.

MK "TW" female couplers of stainless steel

special types with bent lever
