ZVF 50 JET
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C
SL 16 AdBlue
black or blue; specially made for urea solution (DEF, ARLA)
GasGuard LPG nozzle GG30: optional Magnet in the guard
For contactless activation of dispensers with reed switch technology
Elaflex website:
content driven, always current data
Elaflon Plus FEP
hose assemblies, lacquer filling
LNG Refuelling
N-LNG Nozzle, push handles to couple
Colour production: mixer
UTS hose assemblies
HD 38 C NEON, Aljac bonding reel
Airfield refueller (e-refuelling technology)
ZVA Slimline 2 GRVP - spout with vapour suction inlet
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ERV ZS from DN 250 (PN 16)/350 (PN 10):
Tied Flanges – Type ZS, Tie rods with outer limitation in spherical discs and conical seats
Fuel delivery at the petrol station
LTW 75 fuel delivery hose
Composite hose Danoil 7GG, DDC-M Dry Disconnect Coupling, airport depot
ZVF 50 AVGAS for aircraft refuelling
with ER 583
Dispenser picture to distinguish the three different kinds of Safety Breaks
Hose Break, Pump Break, Nozzle Break
Elaflex hose assemblies
Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
Urea solution for trucks: ELAFIX 40 magnet adapter in filler inlet of AdBlue tank
Safety against misfuelling (mixup with Diesel)
Production MannTek, Sweden
ContiTech Production hose
Dispensing hose, after mandrel removal, before coiling
Oasis FV103 Fill Valve, NC 104 Nozzle Coupler, CNG bus refuelling
Equipment truck for dangerous goods accidents
suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf
Type PCS 50 (Polypal Clean DN 50 mm)
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Tecnopal chemicol hose assembly
on hose reel
Polypal Clean hose
Equipment truck for dangerous goods accidents, Elaflon PTFE universal hose assembly, DDC Dry Disconnect Coupling
HB 50 ST tar spraying hose
Pressure hose for road construction machines, especially for hot bitumen and heavy heating oil. Temperature range: - 25° C up to + 220° C. Meets EN 13482, Type 2 SB/B (DN 19 and DN 32 analogue).
Bunkering ship: FHD hose assemblies
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
