Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose
ERV-GR ... ZS
"Green Band" Rubber Expansion Joints with limiters in chemical pumping system
Ship bunkering with LNG
towards the end of the bunkering process
ROTEX 200.10 SS TAS
Rubber Expansion Joint with PTFE lining and PTFE vakuum support ring
Airfield fixinstallation: Hose Reels JET, AVGAS
Type HD-C, aviation hose, ZVA 32
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ZVA Slimline 2 GR, Coax hose assembly
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
DN 1" SS
Double nipple stainless steel
SD 38 Pyropal
Steam hose with steel braids for wet saturated steam up to 18 bar (210° C) and hot water up to 120° C. For cold water up to 25 bar. Minimum burst pressure 180 bar (1 : 10 safety factor
Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings
Camlock hose couplings: system comparison
right hand side - industry standard, with cable tighteners to fix levers. Left hand side: Easyloc from Elaflex with automatically secured levers.
Drum unloading chemical industry
UTS hose assemblies with Easyloc cam locking couplings
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, black.
Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY
EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp
Tank truck and trailer with HD 45 hose reel, ZV 500 nozzle
Dry Evotek Coupling DEC
Dry Coupling for the chemical industry, road tanker unloading with UTS hose assembly
Ship bunkering
'Yellow Band' collapsible high
Fluorline EFL 21
Universal pump hose DN 21 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue® urea solution. Temperature range - 40° to + 100° C. Burst pressure > 64 bar.
MK 50 SS
TW female coupler, stainless steel
ERV-R Red Band rubber expansion joint, ship engine room
LNG ship bunkering
DCC Dry Cryogenic Coupling, CBC-PERC Cryogenic Breakaway Coupling
ZVG 2 K (Korea)
suitable for passenger and heavy duty vehicle refuelling in markets utilising the 'J15' fill point receptacle.
ERV-OR ... ZS
"Orange Band" Rubber Expansion Joints with limiters; heating plant
CHD 32
Lilac Band chemical hose without helix, DN 32
ELAFLEX Hamburg
Certificate pressure test
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 DISH nozzle, LPG 16 hose assembly, ARK 19 Safety Break
SMC 50-2"
Female hose coupling of steel with Spannloc clamps
Hose assemblies for petroleum based procucts
LTW 75, VX 80-3, MannTek DDC-M80-3Ms & TW 63, SFX 63 TW
Anti-Kinking Spirals 'KSS' and 'KSS-SD'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
