Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 7
ZVA HV for AdBlue®, SSB 16 SS, SL 16 for AdBlue®, Elafix 40
Urea solution (DEF, ARLA 32) for trucks: nozzle, Safety Break, hose assembly and adapter for the vehicle AdBlue® filler inlet to avoid misfuellings.
Unloading chemical road tanker, Methanol
UTS hose assembly
Elapharm EPH 25 with EN 1092-1flange fitting, free of dead spaces
ZVA Slimline 2 TMV nozzle for Diesel with DRIP STOP spout
Oasis HC308 Ultra Fast Quick Fill Coupler for CNG
M-St 50 SSE
Female threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
ROTEX 80.16
Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative
ELAFLEX hose quality: braided reinforcements
serve for flexibility, low weight and increased lifetime
Cargo loading / unloading of ship, STW 150, Vapour Line
Italy
SPANNFIX pinned safety clamps of stainless steel
SX 75 NR SS
ELAFLEX Hamburg
Assembling Spannloc hose clamps
UTS hose assembly with AMKC 32 SS and AVKC 32 SS
'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps
Hot stamping process, TW coupling part
ELAFLEX Hamburg, stock
HD-C, underwing nozzle
Aircraft refueller, large reel with aircraft refuelling hose and underwing nozzle
Dantec Production hose
Composite hoses: reeling
Slimline quality dispensing hose for the forecourt
ELAPHARM and SD Pyropal steam hose
Pharmaceutical production
Underwing refuelling A 380
ZVA 25, bus refuelling
KR 50 - 21/2", HD reel hose
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
Drum filling
with CHS chemical hose assembly
Slimline 16 blue
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
AN 2 St
Welding nipple steel
Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR
For regions with exceptionally hot summer conditions which may lead to particularly high fuel temperatures we offer High Temperature (HT) nozzle types, available for ZVA Slimline 2 and ZVA Slimline 2 GR.
GSD 50 Hy
Coupling seal for TW couplings, CSM green
Ferrule threaded hose coupling M 19-1" cr
for petrol station dispensing hoses
