Coax hose assembly, section view
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapter Rail Tanker Dischharge Coupling KWK SS/Vi x VK 50 SS/Vi
ELAFLEX seals
MC 38-11/2" Ms
Female hose coupling for hoses, brass, with Spannloc clamps
BD 63, HD 63 C
Aircraft refuelling hoses with ELAFLEX Hose Beads 'BD'. Details see Information 7.17
KSS-SD of stainless steel
for saturated steam hoses. These hose assemblies are subject to high wear. The main stress area for hose assemblies is also at the joint end is protected.
ERV-R 150.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ERV VSD:
ERV with vacuum support spiral. Spiral of AISI 316 Ti, used when the vacuum resistance of the chosen ERV is not sufficient.
ZVA LV for AdBlue® with EA 075 LV
Urea solution (DEF, ARLA 32) for Light Vehicles
Fluorflex FXD universal hose assemblies with anti kinking spiral KSS
extremely flexible PTFE hose with maximum bending radius and safety against kinking
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps) and LMS solvent hose. Direct connection of a hose assembly to the IBC.
ZVA Slimline 2 GR nozzle
with Coax hose assembly (one side open end, inner vapour hose visible)
Aircraft refuelling
Carter Underwing Nozzle, HD63C Neon, ZVF 50 JET, SC 50 Al, HD 50 C, Hose Bead BD 50
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose
Flexible bronze pipe connectors
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Section view of a DS 2 swivel
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, bonding cable
AMX 50 PA
Ammoniac hose to EN ISO 5771 for water-free, liquid and gaseous ammonia.
LNG ship bunkering
DCC Dry Cryogenic Coupling, CBC-PERC Cryogenic Breakaway Coupling
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Swivel assembling
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting ZVA
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
Hot stamping process, production TW coupling parts
Terminal / gantry: 'Polypal Oil 100' and 'TW 100' hose assemblies for bottom loading of road tankers
AN 2 Al
Welding nipple aluminium
SVC 50-2"
Male hose coupling of steel with Spannloc clamps
FGN 2 St
Flange with male thread, steel zinc plated/chromated
Polypal Clean hose assembly
Pharmaceutical production
ZVA Slimline 2 GR
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
