Ship bunkering with LNG
CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media
Elaflon Plus FEP hose assembly, crimped foodstuff fitting
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
ELAFLEX Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
ERV-G
with vacuum support spiral
ELAFLEX Tanktechnik, Production Plettenberg / Germany
ZVA long term testing
ZVA_AdBlue_LV_2-Stufen-Anschlag_Step2_mod
Use - 2/2
ERV-R 200x175.16 ZS 4
Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ZVA Slimline 2, guard no. 1, black scuffguard, blue product sleeve, SL 16 hose assembly with blue Colour Sleeve
ERV-G ... TW
Dispenser / hydrant inlet pipe
Universal hose assembly UTL 63 with VC 63-3" SS / SS and MK-A 80 SS
Elaflon PTFE
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Terminal loadingarm
'SBC-C'
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
Hose Reels group picture
Movable, pneumatic rewind system, active Vapour Recovery (VR) for gasoline fuels
Hose assembly with STKC 75
Storz coupling with Spannloc clamps
M-St 50 SSE
Female threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
Coax hose assembly, section view
LNG Refuelling
LNG Nozzle 'N-LNG'
ELAFLEX Tanktechnik, Production Plettenberg / Germany
Swivel assembling
Rail tanker unloading of petroleum based products
FWS PP St/St composite hose, MannTek Dry Disconnect Coupling, KWZ adapter
Hose assembly TW 63 with VX 63-11/2" and DDC-M 65 Al
TW hose with Dry Disconnect Coupling
UTS 50 hose assembly
with MannTek DDC Dry Disconnect Coupling; use eg. as road tanker hose for filling AdBlue® petrol station tanks
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
BD 63, HD 63 C
Aircraft refuelling hoses with ELAFLEX Hose Beads 'BD'. Details see Information 7.17
Dust caps and plugs for MannTek Dry Disconnect Couplings
Tank container, Antarctica: HD-LT hose assembly, ZVF 25 LT nozzle
Low Temperature types
HD 50 C, Carter Underwing Nozzle, Aljac Lanyard Reel
GasGuard LPG nozzle GG1DN
suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure: 1.7 cm³.
