DCC Dry Cryogenic Coupling for LNG
Coupling process
ZVA Slimline 2, filler inlet, Diesel refuelling
KR 50 - 21/2"
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
Nozzles and hose assemblies for the forecourt
ZVA Slimline 2, ZVA Slimline 2 GR, Slimline hose assemblies
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
Marine bunkering and cargo hoses
ship to shore bunkering
ERV TA:
ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.
Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings
Scandinavia
Railtanker
MannTek DDC-V 80 F Dry Disconnect Couplings (tank unit with flange), Pressure Caps PN 25 with pressure relief
Boat refuelling, ZVA 25
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
ELAFLEX Hamburg
Aerial view over the ELAFLEX premises
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Flange FGN 2" SS x VK 50 SS/Vi, FGN 3" SS x VK 50 SS/Vi, FGN 4" SS x VK 50 SS/Vi
Oasis BV706 ball valves with Code 62 flange connection, for CNG
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Development
Filling plant for special gasoline types
ZVA 25 solvent type with special seals, Slimline hose assemblies
SSB 25 Safety Break: Abriss
ZVF 50 JET overwing refuelling
LeverAssist hold-open aid for comfortable refuelling
Solvapal hose assemblies
Container cleaning
ELAFLEX Hamburg
New narrow aisle stock (2018)
ERV ZS:
Tied Flanges – Type ZS, Tie rods with outer limitation in rubber bushings
ELAFLEX Hamburg
Coax hose assembling, colours
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
Unloading chemical road tanker, Methanol
UTS hose assembly
Production TW couplings
BD 63, Hose Beads at airport depot
Polypal Plus 50 universal hose
with seamless, black, conductive UPE lining. For almost all liquid and pasty chemical and petroleum based products and solvents. Meets EN 12115.
Hose assemblies
for dangerous goods: ELAFLEX quality
Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50
Hose assemblies and Rubber Expansion Joints for the chemical industry
ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad
