Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings
ElaSil® Silicone hose assemblies DN 13-102
For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps). Direct connection of a hose assembly to the IBC.
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Slimline 16 yellow
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
ZVA Slimline 2 GR, black, guard 3 - side view
Customer protected special design ZVA Slimline 2 & ZVA Slimline 2 GR nozzles
Ship bunkering loading and unloading, Hose Reels, HD hose, ZV 500
Bunkerboat
ELAFLEX Hamburg
Assembling Spannloc hose clamps
UTS 50 hose assembly
with MannTek DDC Dry Disconnect Coupling; use eg. as road tanker hose for filling AdBlue® petrol station tanks
TW filll adapters:
TWV 7 (VK 50 x MB 80), TWÜ 13 (VK 50 x 21/2" fem.)
Unloading petroleum products at the service station (road tanker to UST)
LG hose assembly for gravity discharge
Flexible bronze pipe connector BWO
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Oasis HC208 Quick Coupler, CNG loading
PAL hose assemblies:
PCD 32 / RMC-SS, Butapal 32 / ACMX, Polypal Plus 50 / SFC 50 SS, Tecnopal 38 / MKX-SS, Pyropal 38 / MC38
Oasis BV708, 1" ball valves, isolation valves, CNG trailer loading
Equipment truck for dangerous goods accidents
suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf
ERV-R
"Red Band" Rubber Expansion Joints; wastewater pump
FWS composite hoses / hose assemblies
Type FWS PP with female threaded fitting, Type FWS PTFE with stainless steel flange
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO
Simultaneous Refuelling/Filling of Diesel and AdBlue®
Picture 2
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading
Hose assembly with MKX 75 SS and VB 80 SS
TW female coupler with Spannfix clamp, plug
Offset UST filling point, LTW hose assemblies with TW couplings
Operator
Upstream Oil Industry, TW hose assemblies
Kuwait
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Ship bunkering
FHD hose assemblies, Port of Gothenburg / Sweden
HD-C Neon, large reel, VK 100 Ms, MB 100 Al
Connection UTS hose assembly
Belgium
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
