Assembling Spannfix hose clamps

Rubber Expansion Joint ERV-BR 80.16

BR Expansion Joints, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products (e. g. carbon-blacks). Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e.g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

ZVA Slimline 2

with Sight Glass

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

PAL hose assemblies:

PCD 32 / RMC-SS, Butapal 32 / ACMX, Polypal Plus 50 / SFC 50 SS, Tecnopal 38 / MKX-SS, Pyropal 38 / MC38

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (English)

ERV Rubber Expansion Joints

Picture 1

ZVA Slimline 2 / ZVA Slimline 2 GR

Petrol station nozzles with (top) and without vapour recovery (below)

ERV-CR

"CR" Rubber Expansion Joints - installation in sewage plant

Section view of a CSB 21 COAX Safety Break

BD 63 Hose Beads

to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.

ERV-R

"Red Band" Rubber Expansion Joints with limiters / pump station

Compact Line HD 50, Hose Reel Spring Rewind

FEP 5O, MannTek DDC-M 5O SS

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

AMK-St 50 SS, AVK-St 50 SS

'Camlock' stainless steel female and male hose tails to EN 14420 - 7

ZVA Slimline 2 GR, special type with bellows, black, guard 3 - side view

Camlock Cam Locking male adapter AVK 50-2" Ms (brass)

AMK 25 EASY

EASYLOC ('Camlock' stainless steel coupler to EN 14420 – 7 for male adapters AVK with captive seal) with lever arrest

Ship loading various media - STW 150 and UTS 150 hose assemblies

MannTek DGC DryGasCouplings for L.P. Gas

DGC-M 80-3", DGC-V 80-3" with DDC-K dust cap

ZVA Slimline 2 GR nozzles

UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS

AMKC 50 SS

'Camlock' stainless steel steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps

Underwing refuelling, HD-C

Aircraft dispenser, pit

Slimline 21 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
