MK-A 80 SS
MK 80 SS with active safeguard lever
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
ELAPHARM Type EPH-OHM G
electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).
FFC 50.16 St
Fixed flange hose fitting of steel, with Spannloc clamps
DDC-M 80-3" Ms
MannTek Dry Disconnect Coupling, DN 80, gunmetal
Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral
VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571
Forklift refuelling with LPG (L.P. Gas, Autogas)
GasGuard nozzle, LPG 16 hose; dispenser
Sand casted products to your design
In our modern foundry we can produce complex sand casted aluminium, bronze and gunmetal products to your requirements.
Orange Band L.P. Gas hose type LPG
Premium quality for highest safety and best handling
Wear Advice
VHD 50
Elaflex Hamburg
Main building / entrance
Adapter coupling DGC / ACME
DGC-V 50 x 1 3/4" ACME. Dry Disconnect Couplings are state of the art for the fast and safe loading/unloading for liquefied gas (LPG). Connecting with standard fittings is still possible with adapters, like this one with ACME thread.
Hose assembly for L.P. Gas
LPG 50, DGC-M 50
ERV-GS
"Yellow Steel" Rubber Expansion Joints / ship engine room
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
ERV-OR
"Orange Band" Rubber Expansion Joints for L.P. Gas, road tanker
Nozzle boot NB-GG
for GasGuard LPG nozzles
Aircraft Refuelling Skid
HD-C hose assembly, ZVA 32 nozzle, SG1Al sight glass, hose reel made by Elaflex Italy
ZVA Slimline 2
with Sight Glass
SG 1" 1x0 Al Propeller
Sight Glass with propelller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
PSB Pump Safety Break for High Hose Dispensers
Construction of Elaflex composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
ContiTech Production ERV
Vulcanisation
Construction of Elaflex composite hoses type FWS
Sectioned view of a composite hose, denomination of the components - detail view
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, yellow.
LNG bunkering / loading of a ship
MannTek DCC Dry Cryogenic Coupling
Filling of Heating Oil Tanks: Adapter KR 50-21/2"
for difficult to reach filler inlets
MK 80-2" AG
TW female coupler, brass, with reduced male thread (special type)
LMD 25 Blue Band solvent hose
without helix
EA 866 scuffguard orange with ZVG 2 ACME nozzle
The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space
