Media Library / Images

IBC unloading

Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.

RS 1 x 11/4 SS

Reducer Female/Male

Composite hose assemblies with 'COPSAFE' , suitable for COP systems (cross-over prevention)

electrical conductivity

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

ZVA 25 GR

For the filling of small containers and IBC with solvents. With vapour recovery.

Slimline 21 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

ZVA Slimline 2 GR, Coax hose assembly

UK

Slimline 16 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Boat refuelling, ZVA 25

Elaflex Tank + Pipe Fittings

DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75

Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose

Fuel grade identification for ZVA to standard

Attach with EK 145 Product Badge

ERV Rubber Expansion Joints

Picture 2

Oasis FV103 with NC203 P30, Light Duty Fill Valve and Transit Nozzle for CNG

VKC 75 SS

TW male hose coupling, stainless steel, one part, with Spannfix clamps, with protecting "K"-Ring

Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY

EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp

Guards for ZVA nozzles

suitable for all dispensers, world wide

ZVF 50 helicopter refuelling with HD-C hose assembly

France

HD-C NEON hose with new, REFLECTING marking

VB 80 ADR SS with pressure relief

Plug for MK 80
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation

Oasis FV103 Fill Valve with extension, CNG dispenser

Adapter: MK 50-45° SS x VK 50 SS

The lever is bent to enable lever arrest (safe position when coupled)

ZVA-RG

Automatic nozzle ZVA DN 19, of red bronze (gunmetal), for solvents and corrosive media. Flowrate up to 60 l / min.

GasGuard LPG nozzle GG1DN

suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure: 1.7 cm³.

Manifold for incoming media, chemical industry

Elaflon PTFE universal hose, AMK 50 EASY (Easyloc cam locking couplings with automatic lever lock)

MK-A 80 SS, TW female coupler with Active Safeguard Lever, VB 80 SS

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Production Picture 18

DDC-V 50 SS F

MannTek Dry Disconnect Coupling, DN 50, stainless steel, with flange connection

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

FSH flame protection cover for ERV rubber expansion joints

Use e.g. in ship engine rooms
