DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
Hose assembly TW 63 with SFX 63
TW hose with helix, 'TW' flange with hose tail and Spannfix clamps of aluminium
HD-C, aircraft refueller
ERV-G 80.TW
"Yellow Band" Rubber Expansion Joints; tank truck
ZVA Slimline 2, black, guard 3 - side view
ELAFLEX Hamburg
ELAFLEX stock
Anti-Kinking Spiral 'KSS'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the new Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle
Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt
VX 50-2" NPT SS
Male hose coupling 2" NPT of stainless steel with Spannfix clamp
ELAPAC FD 50 Oval flange seal
GasGuard LPG nozzles
and LPG 16 hose assemblies for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane.
ZVF 50 JET overwing refuelling
with HD-C hose assembly
ERV-G ... TW
"Yellow Band" Rubber Expansion Joints; tank truck
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, black.
Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)
Slimline dispensing hose SF (sulfur-free)
Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
Quality in the detail: valve assembly of a ZVA Slimline 2 petrol station nozzle
ZVA "LT" nozzles
Low Temperature type -40° C for cold regions
MKC 75 SS
TW female one-part coupler, stainless steel
Terminal Railtanker
LTW 100, MK 100, VK 100, SBC 100-4, FFBV 100
Urea solution filling of a car:
ZVA LV for AdBlue®, Slimline 16 for AdBlue® (blue cover)
ZVA Slimline 2 nozzle, yellow
Bonding Reel, HD 100, ZVF 50 JET, Aljac Closed Circuit Sampler
Airfield refueller
TW 100, DDC-M 100, airport depot
Dry Disconnect Coupling for Loading/Unloading
Heating oil delivery: ZV 400 nozzle, HD reel hose
Hoses for Liquefied Petroleum Gas / Autogas
LPG 13, LPG 16 black/orange, LPG 19
Ship bunkering
TW hose assembly
