Flexible bronze pipe connector BWO
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Cabinet of road tanker:
MK 80 with VB 80 ADR SS (plug with pressure relief)
Road tanker hose reel, made by Elaflex Italia
with LPG hose assembly
MK 80-2" IG
TW female coupler, brass, with reduced female thread (special type)
Ship loading with chemicals
UTS 150 hose assembly, ARK-S Safety Break Coupling
Bunkering ship: FHD hose assemblies
RS 3/4 x 1 SS
Reducer Female/Male
Aircraft refuelling: MannTek sampling unit in hydrant system
Elaflex Pacific (Australia)
Construction
ContiTech Production ERV
Vulcanisation
ZVG 2 EURO nozzle for L.P. Gas / Autogas, LPG 16 hose assembly
HB hot bitumen hose
'Brown Band', for filling of hot bitumen and heavy fuel oil. Temperature range - 25° to max. + 200° C. Meets EN 13482.
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Unloading chemical road tanker, Methanol
UTS hose assembly
Cabinet of road tanker:
hose tubes, TW hoses, TW couplings
SMS 19-3/4"
Steam hose couplings of steel to EN 14423. With bolted clamps of hot stamped brass. For saturated steam hoses up to 220° C, compressed air, oxygen, oils up to 25 bar W.P. Hose tail and union nut of steel Zn / Cr.
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, vent hose assenbly with 'VC-LNG'
Production MannTek, Sweden
Customer protected special design ZVA Slimline 2 GR nozzle
ElaSil® Silicone hose assemblies DN 13-102
For Pharma, foodstuff and cosmetics industry.
ELS 25 with Camlock Cam Locking Coupling, foodstuff thread and Triclamp.
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, red.
LPG Autogas Adapter (filler inlet) ACME
ACME thread 1 3/4"
Stainless steel couplings with PFA coating, type "...SSE"
Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Fuel Grade Identification to EN 16942 for ZVA Nozzles
Type EK FGI
ELAFLEX refuelling equipment:
Quality is in the detail.
VC 75-3" SS / SS
Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
ERV-R ... ZS
"Red Band" Rubber Expansion Joints with limiters
Production plastic precision parts
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
