Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Oasis NC 103-200 Bus & Truck Nozzle
RD 50 seal, NBR blue
for foodstuff threaded couplings
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
SG 1" 1x0 Al
Sight Glass with propeller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
ERV Rubber Expansion Joints
Picture 1
ERV-W 80.16 ZS 2
White Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ERV-W 80.16 SS TA
White Band Rubber Expansion Joint with "TA" PTFE lining
Coloured hose assemblies for the forecourt
Slimline 21, M 21-1" NR
DAC-V 65
MannTek Dry Aviation Coupling
SC 50 SS
Spannloc clamps, stainless steel
ELAFLEX Hamburg
Assembling ERV small DN
BD 63 Hose Beads
to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
ZVF 50 JET overwing refuelling
with HD-C hose assembly
ELAFLEX Hamburg
Stock intake quality check – measurements
TW hose assembly, airport depot
Elaflon Plus FEP hose assemblies, one side open end
up to DN 50 grey cover / from DN 63 black cover
ELAFLEX Hamburg
Commissioning / Pick by Voice
KWZ 3" Al
Rail tanker adapter with male thread connection, aluminium
PAL hoses for the chemical industry
LBS 50 hose assembly for foodstuffs, FDA conform
with RMC 50 SS/SS (DIN 11851 foodstuff threaded coupling and Spannloc clamps of stainless steel)
ZVA Slimline 2
Automatic nozzle DN 19, for flowrate max. 80 l / min. Green Product Sleeve and Scuffguard, Slimline dispensing hose assembly
Rail car adapter type KWZ, one end with rail car thread 5½, other end 3" male BSP
IBC unloading
Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.
NB-ZVF 50 SR, ER 583 PTL, Aljac Closed Circuit Sampler (CCS)
Nozzle boot f. ZVF 50 with additional spout retainer
Swivels DG of stainless steel
Swivels serve to avoid hose torsion (increase of life span) and help for easier handling
Boat refuelling, ZVA 25
ZVA Slimline 2 and ZVA Slimline 2 GR, special colour light green
Adapter: MK 50-45° SS x VK 50 SS
The lever is bent to enable lever arrest (safe position when coupled)
Stainless steel hose tails - new shape
Stainless steel hose tails - optimized shape for enhanced operational safety, suitable for temperatures up to 150° C. Details see Information 5.15.
